Book Printing Machine
Ronald Book Master

Ever wondered what makes you pick a book? Well, the content is the first but we can’t ignore the look of a book. While picking our favourite book, we always ensure the font size and print quality or else it will spoil the fun of reading. The daunting task of printing a book is carried out easily with the help of book printing machines. Infused with amazing features, such machines work the best when it comes to enhancing the printing capability. While it cuts off the labour cost, it also allows the printing process to be faster. If we have to name one such machine, it would be Ronald book master which delivers the perfect solution for high-quality books and magazine printing.

While Ronald book master is considered one of the best book printing machines in India because it can print books of various sizes with quality printing and that too, at a faster pace. Being easy to install, it is highly preferable by companies which are looking for sharp print quality and uniform printing.

Highlights of Machine
  • Centralized oil pressure lubrication
  • High speed automating printing
  • Lever-type swing-down ink fountain
  • Cloth dampening system
  • Dampening rollers of stainless steel
  • Safety guards with powder coating
  • Motorized dampening with variable speed
  • Centralized water circulation system
  • PU-covered ink vibrator roller

Applications of Ronald Book Master Book Printing Machines

Being the most prominent book printing machine manufacturer, Ronald India has its best product to offer. Named as Ronald book master, this machine is in high demand due to optimum performance with minimum downtime. Besides, it can print various sizes of books without compromising on quality. Owing to its unique features, it is able to meet the needs in various applications like:

  • Periodicals
  • Books
  • Circular Printing
  • Commercial Printing
  • Text Book Printing

Signature Options

Products Cut-off Broadsheet Tabloid Quarter Fold (Magazine) 1/8 Fold (Booklet) Double Parallel or Digest (2-on)
Signature Size
508mm
368mm to 444mm x 508mm
254mm x 368mm to 444mm
184mm to 222mm x 254mm
184mm to 222mm x 127mm
127mm x 368mm to 444mm
(Untrimmed) sizes
533mm
368mm to 444mm x 533mm
266.5mm x 368mm to 444mm
184mm to 222mm x 266.5mm
184mm to 222mm x 133.25mm
133.25mm x 368mm to 444mm
Depending on web width used
546mm
368mm to 444mm x 546mm
273mm x 368mm to 444mm
184mm to 222mm x 273mm
184mm to 222mm x 163.5mm
136.5mm x 368mm to 444mm
560mm
368mm to 444mm x 560mm
280mm x 368mm to 444mm
184mm to 222mm x 280mm
184mm to 222mm x 140mm
140mm x 368mm to 444mm
578mm
368mm to 444mm x 578mm
289mm x 368mm to 444mm
184mm to 222mm x 289mm
184mm to 222mm x 144.5mm
144.5mm x 368mm to 444mm
630mm
368mm to 444mm x 630mm
315mm x 368mm to 444mm
184mm to 222mm x 315mm
184mm to 222mm x 157.5mm
157.5mm x 368mm to 444mm

Super Jaw (1:2)

Broadsheet
Max. Speed cph		 Broadsheet
Max. No. of Webs		 Tabloid
Max. Speed cph		 Tabloid
Max. No. of Webs		 Quarter fold (Magazine)
Max. Speed cph		 Quarter fold (Magazine)
Max. No. of Webs		 1/8 fold (Booklet)
Max. Speed cph		 1/8 fold (Booklet)
Max. No. of Webs		 Double Parallel or Digest(2-on)
Max. Speed cph		 Double Parallel or Digest(2-on)
Max. No. of Webs
30.000
6
30.000
5
22-24,000
2
16.000
2
16.000
2

Technical Specifications

508mm Cut Off 546mm Cut Off 560mm Cut Off 578mm Cut Off 630mm Cut Off
Cut Off
508mm   20”
546mm   21-1/2”
560mm   22”
578mm   22-3/4”
630mm   24.80”
Plate & Blanket Width
889mm   35”
889mm   35”
889mm   35”
889mm   35”
889mm   35”
Plate Length Gripper
516mm   20.31″
554mm   21.81″
568mm   22.36”
586mm   23.07″
638mm   25.11”
(Unbent) Slit
539mm   21.22″
577mm   22.71″
591mm   23.26″
609mm   23.97″
661mm   26.02”
Plate Thickness
0.28mm   0.011″
0.28mm   0.011″
0.28mm   0.011″
0.28mm   0.011″
0.28mm   0.011″
Blanket Length including bars
556mm   21.88″
594mm   23.38″
608mm   23.93″
626mm   24.64″
678mm   26.69”
Blanket Thickness
1.65mm   0.065″
1.65mm   0.065″
1.65mm   0.065″
1.65mm   0.065″
1.65mm   0.065″
Paper width full reel
690-889mm   27″-35″
690-889mm   27″-35″
690-889mm   27″-35″
690-889mm   27″-35″
690-889mm   27″-35″
Max. reel dia
1070mm   42″
1070mm   42″
1070mm   42″
1070mm   42″
1070mm   42″
Printing Length
482mm   18.97″
520mm   20.47″
534mm   21.02″
552mm   21.73″
604mm   23.77”
Blanket thickness with under packing
2.1mm   0.082″
2.1mm   0.082″
2.1mm   0.082″
2.1mm   0.082″
2.1mm   0.082″
    • Special Cut-Off on Demand
    • Web width can be up to 915mm
    • Stocks handled: Paper Reel (Uncoated) 38-80 gsm.
    • Ronald Web Offset Pvt Ltd. reserves the right to vary the specifications of RONALD presses without prior information resulting from its policy of consistently improving and updating of all products.
